機組型號 | 輸出功率(kw) | 電流 | 柴油機型號 | 缸數(shù) | 缸徑x行程（mm) | 排氣量（L) | 燃油消耗率（g/kw.h) | 機組尺寸（mm LxWxH) | 機組重量（kg) | |
主用 | 備用 | |||||||||
JHGM220 | 220 | 242 | 397 | 6R1600G10F | 6 | 122x150 | 10.5 | 201 | 3000x1450x1815 | 2800 |
JHGM250 | 250 | 275 | 451 | 6R1600G20F | 6 | 122x150 | 10.5 | 199 | 3000x1450x1815 | 2800 |
JHGM300 | 300 | 330 | 541 | 8V1600G10F | 8 | 122x150 | 14 | 191 | 3000x1480x1975 | 3200 |
JHGM320 | 320 | 352 | 577 | 8V1600G20F | 8 | 122x150 | 14 | 190 | 3000x1480x1975 | 3200 |
JHGM370 | 370 | 407 | 668 | 10V1600G10F | 10 | 122x150 | 17.5 | 191 | 3100x1660x2045 | 3800 |
JHGM400 | 400 | 440 | 722 | 10V1600G20F | 10 | 122x150 | 17.5 | 190 | 3100x1660x2045 | 3800 |
JHGM480 | 480 | 528 | 866 | 12V1600G10F | 12 | 122x150 | 21 | 192 | 3400x1660x2145 | 4500 |
JHGM530 | 530 | 583 | 956 | 12V1600G20F | 12 | 122x150 | 21 | 192 | 3665x1660x2145 | 4500 |
JHGM515 | 515 | 567 | 929 | 12V2000G25 | 12 | 130x150 | 23.88 | 203 | 4045x1730x2150 | 5400 |
JHGM640 | 640 | 704 | 1155 | 12V2000G65 | 12 | 130x150 | 23.88 | 202 | 4110x1730x2150 | 6200 |
JHGM730 | 730 | ,803 | 1317 | 16V2000G25 | 16 | 130x150 | 31.84 | 198 | 4465x1730x2300 | 7000 |
JHGM800 | 800 | 880 | 1443 | 16V2000G65 | 16 | 130x150 | 31.84 | 198 | 4550x1730x2300 | 7250 |
JHGM910 | 910 | 1001 | 1642 | 18V2000G65 | 18 | 130x150 | 35.82 | 202 | 4760x1900x2500 | 8200 |
JHGM1100 | 1100 | 1210 | 1985 | 12V4000G23R | 12 | 170x210 | 57.2 | 195 | 6500x2200x2505 | 12000 |
JHGM1320 | 1320 | 1452 | 2382 | 12V4000G23R | 12 | 170x210 | 57.2 | 189 | 6500x2200x2505 | 12500 |
JHGM1470 | 1470 | 1617 | 2652 | 12V4000G63 | 12 | 170x210 | 57.2 | 193 | 6500x2200x2505 | 13000 |
JHGM1670 | 1670 | 1837 | 3013 | 16V4000G23 | 16 | 170x210 | 76.3 | 192 | 7525x2200x2545 | 14500 |
JHGM1800 | 1800 | 1980 | 3248 | 16V4000G63 | 16 | 170x210 | 76.3 | 191 | 7525x2200x2545 | 15000 |
JHGM2000 | 2000 | 2200 | 3609 | 20V4000G23 | 20 | 170x210 | 95.4 | 195 | 8300x2555x2695 | 20500 |
JHGM2240 | 2240 | 2464 | 4042 | 20V4000G63 | 20 | 170x210 | 95.4 | 193 | 8300x2555x2695 | 21000 |
JHGM2400 | 2400 | 2640 | 4330 | 20V4000G63L | 20 | 170x210 | 95.4 | 192 | 8300x2555x2695 | 21000 |
聯(lián) 系 人 ：賴先生
公司電話：86-0596-2922178
公司傳真：86-0596-2922178
手機號碼：13859203456
電子郵箱：jennifer@waetapower.com
公司地址：漳州市藍田經濟開發(fā)區(qū)龍騰北路40號D
